· For Use in Horizontal Distribution & backbone Cabling
· 4/16Mbps Token Ring (IEEE 802.5)
· 10/100/1000 BASE-T (IEEE 802.3)
· 155Mbps
· ATM LAN 1.2G
· 100Mbps TP-PMD
· ISDN, ADSL
· Analog & digital voice (VoIP) and video
· Full broadband & baseband video
| Item | Unit | Information |
| Feature | ||
| Category | ANSI/TIA-568-C.2 Category 6 (250Mhz) | |
| Approvals | UL Listed | |
| Standards | 47 CFR part 68 | |
| Wiring Scheme | T568A or T568B | |
| Electrical | ||
| Current Rating | Amps | 1.5 |
| Insulation Resistance | M-ohm | >500 |
| Contact Resistance | m-ohm | <20 |
| DC Resistance | ohm | < 0.1 |
| Dielectric withstand voltage, RMS, contact to contact | VAC | <1000@ 60Hz |
| Mechanical | ||
| Insertion Life | Mating Cycles | 750 |
| Pulling force | lbs(N) | 20 (89) |
| Temperature | ℃ | -40~68 |
| Humidity | % (RH) | 10~90 |
| Contact Accept | AWG | 23 ~ 26 AWG Solid wire |
| Physical | ||
| Housing and Door | Acrylonitrile Butadiene Styrene (ABS resin) + Polycarbonate (PC resin)
UL94V-0 rated |
|
| Cap | Polycarbonate (PC resin), UL 94V-2 rated, Transparent Black | |
| Contact Bracket | PC, UL 94V-2 rated, Transparent | |
| IDC Block | Polycarbonate (PC resin) + Glass Fiber, UL94V-2 rated | |
| IDC Terminals | Phosphor Bronze, plated with tin over nickel underplate | |
| Jack Contacts | Phosphor bronze flat wire, plated with 1.27um (50uin)
thick hard gold on contact area over nickel underplate |
|
| PCB | FR4, UL 94V-0 rated | |
